Panel mounted socket 229A

Poles
Voltage
Clock position
  • screw terminals
  • straight
  • Part no.229A
  • EAN4015394001232
  • Std. Pack. 10
You can manage our products in various lists in the shopping list / shopping basket area.
Please give the new list a name
  • Please enter a list name
  • The list name already exists
  • Please enter a valid list name

Technical specifications

Panel mounted socket 229A

Ampere 32 A
Poles 3 p
Voltage 110 V
Clock position 4 h
Hertz 50-60 Hz
Connection technology Screw terminals
Contact standard
Protection type IP 67
Flange 85x75 mm
Fixing hole 60x60 mm
Weight 266 g
Declaration of Conformity EAC
CQC
